Dimensions Checking High Voltage Test Equipment with 50Hz Power Supply

Product Description:

The Plug Socket Test Equipment is an essential tool in the field of Electrical Safety Test Equipment, specifically designed for testing plug sockets and ensuring the safety and functionality of electrical connections. This versatile device is also commonly used as EV Connector Testing Equipment and Home Appliance Testing Equipment, providing reliable and accurate results for various testing functions.

One of the key features of this test equipment is its high precision in measuring electrical parameters. The built-in ammeter offers an impressive accuracy of ±1%, ensuring that the testing results are dependable and consistent. This level of accuracy is crucial in assessing the performance and safety of plug sockets, especially in demanding applications.

When it comes to testing functions, the Plug Socket Test Equipment excels in offering a comprehensive range of capabilities. It can perform various tests including Grounding Resistance, Insulation Resistance, Dielectric Strength, Leakage Current, and Contact Resistance. By covering these crucial aspects of electrical testing, this equipment enables users to thoroughly evaluate the condition of plug sockets and identify any potential issues.

For precise voltage measurements, this test equipment provides a Voltage Drop Measurement range of 0~199.9 with an accuracy of ±(3%±1mv). This feature allows users to assess voltage drop across plug sockets with high accuracy, ensuring that electrical connections are functioning optimally and maintaining safe operating conditions.

In terms of design and usability, the Plug Socket Test Equipment is built for efficiency and convenience. It features a Test Stroke of 70mm, allowing for easy and reliable testing operations. Additionally, the equipment operates at a standard Frequency of 50/60Hz, making it compatible with a wide range of electrical systems and environments.

Overall, the Plug Socket Test Equipment stands out as a reliable and versatile tool for assessing the safety and performance of plug sockets. Whether used in electrical safety testing, EV connector testing, or home appliance testing, this equipment offers precise measurements, comprehensive testing functions, and user-friendly design, making it an indispensable asset for professionals in the field of electrical testing and maintenance.

Features:

• Product Name: Plug Socket Test Equipment
• Test Plug: Made Of Hardened Steel
• Testing Functions:
  • Grounding Resistance
  • Insulation Resistance
  • Dielectric Strength
  • Leakage Current
  • Contact Resistance
• Ammeter Accuracy: ±1%
• Power Supply: AC 220V 50Hz
• Test Speed: 5-60times/min

Technical Parameters:

Applications:

HEJIN Plug Socket Test Equipment is a versatile instrument designed and manufactured in China, offering precision and reliability for a variety of testing applications. With a steel rod diameter of 3mm, this equipment is suitable for precise measurements and assessments in various industries.

One of the key applications of this product is in EV Connector Testing Equipment, where it ensures the proper functioning and safety of electric vehicle connectors. The high accuracy ammeter of ±1% allows for detailed current measurements, essential for evaluating the performance of EV charging systems.

Furthermore, this Plug Socket Test Equipment is ideal for Electrical Appliance Testing Equipment, ensuring electrical appliances meet quality and safety standards. The press force of 20N enables the testing of socket connections under different pressure levels, guaranteeing secure and reliable electrical connections.

For Electric Motor Testing Equipment, the voltage drop measurement capability of 0~199.9±(3%±1mv) is crucial for assessing the efficiency and performance of electric motors. This feature allows for precise monitoring of voltage fluctuations during motor operation, aiding in identifying potential issues and optimizing motor performance.

In summary, the HEJIN Plug Socket Test Equipment is a valuable tool suitable for a range of applications, including EV Connector Testing Equipment, Electrical Appliance Testing Equipment, and Electric Motor Testing Equipment. Its high precision, durability, and versatility make it a must-have instrument for professionals in the electrical and automotive industries.
